LC02 lifting column


  • Voltage: DC 24V
  • Rated Power: 50W
  • Max Load capacity: 3500N
  • Speed: 4-12mm/s
  • Protection Class: IP44
  • Minimum Installation Height: 400mm
  • Stroke Length: 240mm
  • Working Frequency: Interrupted working. Load time within 10%

This 3 stage lifting column is designed for massage chairs or medical care table. It can match with foot switch or hand switch for the massage chair or medical platform control. Made up of three extruded aluminium tubes and have a good performance in the stable, reliable and free maintenance benefit.
